HTP1DF02E1B03,HTP1DF02V1C13,HTP1DF02V1G25,HTP1DF02V1J40,先导式电磁阀

点击图片查看原图

型号：	HTP1DF02E1B03,HTP1DF02V1C13,HTP1DF02V1G25,HTP1DF02V1J40,先导式电磁阀
PDF下载：	如需产品详细说明请与销售客服联系
浏览次数：	591

公司基本资料信息

联系人销售员 1581(先生)
电话13861877712
地区江苏-无锡市
地址无锡市会北路28-135

详细说明

HTP1DF02E1B03,HTP1DF02V1C13,HTP1DF02V1G25,HTP1DF02V1J40,先导式电磁阀

型号规格：

接管口径	流量通径 mm	CV值	最小压力	线圈配置	功率		线圈等级	外形尺寸长X宽X高 A x B x H	重量 KG	订货型号以下表中电压为 220CAC 50/60HZ
					VA	W
					AC220V	DC24V
1/8^''	3	0.23	0	D	22	13	F	41x29x83	0.37	HTP1DF02N1A03
	3	0.23	0	D	22	13	F	41x29x83	0.37	HTP1DF02E1A03
	3	0.23	0	D	22	13	F	41x29x83	0.37	HTP1DF02V1A03
1/4^''	3	0.23	0	D	22	13	F	41x29x83	0.36	HTP1DF02N1B03
	3	0.23	0	D	22	13	F	41x29x83	0.36	HTP1DF02E1B03
	3	0.23	0	D	22	13	F	41x29x83	0.36	HTP1DF02V1B03
3/8^''	13	4.5	0.5	D	22	13	F	66x48x112	0.8	HTP1DF02N1C13
	13	4.5	0.5	D	22	13	F	66x48x112	0.8	HTP1DF02E1C13
	13	4.5	0.5	D	22	13	F	66x48x112	0.8	HTP1DF02V1C13
1/2^''	13	4.5	0.5	D	22	13	F	66x48x112	0.7	HTP1DF02N1D13 HTP1DF02V3D13
	13	4.5	0.5	D	22	13	F	66x48x112	0.7	HTP1DF02E1D13
	13	4.5	0.5	D	22	13	F	66x8x112	0.7	HTP1DF02V1D13
3/4^''	20	7.6	0.5	D	22	13	F	75x58x118	0.9	HTP1DF02N1E20
	20	7.6	0.5	D	22	13	F	75x58x118	0.9	HTP1DF02E1E20 HTP1DF02V3E20
	20	7.6	0.5	D	22	13	F	75x58x118	0.9	HTP1DF02V1E20
1^''	25	12	0.5	D	22	13	F	96x70x131	1.4	HTP1DF02N1G25
	25	12	0.5	D	22	13	F	96x70x131	1.4	HTP1DF02E1G25
	25	12	0.5	D	22	13	F	96x70x131	1.4	HTP1DF02V1G25
11/4^''	35	22	0.5	D	22	13	F	131x96x146	2.8	HTP1DF02N1H35
	35	22	0.5	D	22	13	F	131x96x146	2.8	HTP1DF02E1H35
	35	22	0.5	D	22	13	F	131x96x146	2.8	HTP1DF02V1H35
11/2^''	40	30	0.5	D	22	13	F	131x96x146	2.7	HTP1DF02N1J40
	40	30	0.5	D	22	13	F	131x96x146	2.7	HTP1DF02E1J40
	40	30	0.5	D	22	13	F	131x96x146	2.7	HTP1DF02V1J40
2^''	50	48	0.5	D	22	13	F	165x120x167	4.8	HTP1DF02N1K50
	50	48	0.5	D	22	13	F	165x120x167	4.8	HTP1DF02E1K50
	50	48	0.5	D	22	13	F	165x120x167	4.8	HTP1DF02V1K50
法兰4孔	25	12	0.5	D	22	13	F	134x110x160	2.7	HTP1DF02N3F25
	25	12	0.5	D	22	13	F	134x110x160	2.7	HTP1DF02E3F25
	25	12	0.5	D	22	13	F	134x110x160	2.7	HTP1DF02V3F25
法兰4孔	30	22	0.5	D	22	13	F	160x135x175	5	HTP1DF02N3F35
	30	22	0.5	D	22	13	F	160x135x175	5	HTP1DF02E3F35
	30	22	0.5	D	22	13	F	160x135x175	5	HTP1DF02V3F35
法兰4孔	40	30	0.5	D	22	13	F	160x145x180	5.3	HTP1DF02N3F40
	40	30	0.5	D	22	13	F	160x145x180	5.3	HTP1DF02E3F40
	40	30	0.5	D	22	13	F	160x145x180	5.3	HTP1DF02V3F40
法兰4孔	50	48	0.5	D	22	13	F	200x160x207	7.9	HTP1DF02N3F50
	50	48	0.5	D	22	13	F	200x160x207	7.9	HTP1DF02E3F50
	50	48	0.5	D	22	13	F	200x160x207	7.9	HTP1DF02V3F50

HTP1DF02N1A03,HTP1DF02E1A03,HTP1DF02V1A03,HTP1DF02N1B03,
HTP1DF02V1B03,HTP1DF02N1C13,HTP1DF02E1C13,HTP1DF02N1D13,
HTP1DF02V3D13,HTP1DF02E1D13,HTP1DF02V1D13,HTP1DF02N1E20,
HTP1DF02E1E20,HTP1DF02V3E20,HTP1DF02V1E20,HTP1DF02N1G25,
HTP1DF02E1G25,HTP1DF02N1H35,cclair,HTP1DF02E1H35,HTP1DF02V1H35,
HTP1DF02N1J40,HTP1DF02E1J40,HTP1DF02N1K50,HTP1DF02E1K50,
HTP1DF02V1K50,HTP1DF02N3F25,HTP1DF02E3F25,HTP1DF02V3F25,
HTP1DF02N3F35,HTP1DF02E3F35,HTP1DF02V3F35,HTP1DF02N3F40,
HTP1DF02E3F40,HTP1DF02V3F40,HTP1DF02N3F50,HTP1DF02E3F50,
HTP1DF02V3F50,
