二位二通常闭型电磁阀,断电关闭,通电打开阀体材质为SS304不锈钢(常规);
SS316不锈钢(定制)
最大耐压力为:40kgf/cm2
环境温度:0℃～65℃(F级)、0℃～80℃(H级)
产品为系列化生产,体积小,流量大,适用范围广
按阀上所标流向箭头,可任意安装;为增强使用寿命,最好线圈向上,水平安装
电压:AC220V/230V/240V/110V/24V 50/60HZ DC24V/12V +10%到-10%允许波动
线圈可配德国原装NASS线圈 常规备货:AC220V/230V/240V 50/60HZ DC24V
密封件采用聚四氟乙烯材料(Teflon),以适用不同流体的开关控制
| 型号规格： |
|
接管
口径 |
流量
通径 mm |
CV值 |
线圈
配置 |
功率
|
线圈
等级 |
外形尺寸 长X宽X高 A x B x H |
重量
KG |
订货型号以下
表中电压为 220CAC 50/60HZ |
|
|
VA
|
W
|
||||||||
|
AC220V
|
DC24V
|
||||||||
| 3/8'' | 8 | 4.5 | HTA1SF02T3D15 | ||||||
| 15 | 4.5 | D | 33 | 32 | F | 75x52x129 | 1.25 | HTA1DF02T1C15 | |
| 15 | 4.5 | W | 30 | 25 | H | 75x52x129 | 1.25 | HTA1WH02T1C15 | |
| 1/2'' | 15 | 4.5 | D | 33 | 32 | F | 75x52x129 | 1.2 | HTA1DF02T1D15 |
| 15 | 4.5 | W | 30 | 25 | H | 75x52x129 | 1.2 | HTA1WH02T1D15 | |
| 3/4'' | 20 | 9.0 | D | 33 | 32 | F | 85x60x141 | 1.5 | HTA1DF02T1E20 |
| 20 | 9.0 | W | 30 | 25 | H | 85x60x141 | 1.5 | HTA1WH02T1E20 | |
| 1'' | 25 | 13 | D | 33 | 32 | F | 100x70x148 | 1.9 | HTA1DF02T1G25 |
| 25 | 13 | W | 30 | 25 | H | 100x70x148 | 1.9 | HTA1WH02T1G25 | |
| 11/4'' | 35 | 26 | D | 33 | 32 | F | 120x90x168 | 3.6 | HTA1DF02T1H35 |
| 35 | 26 | W | 30 | 25 | H | 120x90x168 | 3.6 | HTA1WH02T1H35 | |
| 1/2'' | 35 | 26 | D | 33 | 32 | F | 120x90x168 | 3.5 | HTA1DF02T1J35 |
| 35 | 26 | W | 30 | 25 | H | 120x90x168 | 3.5 | HTA1WH02T1J35 | |
|
1'' |
25 | 13 | D | 33 | 32 | F | 134x110x185 | 3.4 | HTA1DF02T4F25 |
| 25 | 13 | W | 30 | 25 | H | 134x110x185 | 3.4 | HTA1WH02T4F25 | |
| 11/4'' 法兰连接 |
35 | 26 | D | 33 | 32 | F | 160x135x200 | 6 | HTA1DF02T4F35 |
| 35 | 26 | W | 30 | 25 | H | 160x135x200 | 6 | HTA1WH02T4F35 | |
| 1 1/2'' 法兰连接 |
40 | 26 | D | 33 | 32 | F | 160x145x205 | 6.5 | HTA1DF02T4F40 |
| 40- | 26 | W | 30 | 25 | H | 160x145x205 | 6.5 | HTA1WH02T4F40 | |
