Technical Data
|
Model |
SY-7120- | SY-7220- | SY-7320- | SY-7420- | SY-7520- |
|
Position |
5/2 Way |
5/3 Way | |||
|
Port size |
1/4" | ||||
|
Effective area |
16.2mm2 (Cv=0.9) | 12mm2 (Cv=0.67) | |||
|
Nominal flow |
880 Nl/min | 655 Nl/min | |||
|
Fluid |
Compressed Air | ||||
|
Pressure range |
1.5~7 bar (22~101psi) | ||||
|
Operating temperature |
-5~50°C (23~122°F) | ||||
|
Voltage tolerance |
±10% | ||||
|
Power consumption |
DC / 0.55W | ||||
|
Class of insulation |
Class F | ||||
|
Weight |
102g | 121g | 129g | ||
