负载因素=[通电时间/(通电时间+断电时间)]×100%
|
100%
|
75%
|
50%
|
25%
|
10%
|
|
|
连续
|
间断
|
|||||
|
最长通电时间(S)
|
∞
|
100
|
90
|
30
|
6
|
|
|
电功率(W)
|
9
|
12
|
18
|
36
|
90
|
|
|
安培匝数(20℃)
|
530
|
610
|
750
|
1050
|
1670
|
|
|
电阻Ω±10%(20℃)
|
工作电压 V·DC
|
|||||
|
2.3
|
4.5
|
5.2
|
6.4
|
9
|
14
|
|
|
4
|
6
|
6.9
|
8.5
|
12
|
19
|
|
|
6.3
|
7.5
|
8.6
|
11
|
15
|
24
|
|
|
9
|
9
|
10
|
13
|
18
|
28
|
|
|
16
|
12
|
14
|
17
|
24
|
38
|
|
|
25
|
15
|
17
|
21
|
30
|
47
|
|
|
36
|
18
|
21
|
25
|
36
|
57
|
|
|
49
|
21
|
24
|
30
|
42
|
66
|
|
|
64
|
24
|
27
|
34
|
48
|
76
|
|
|
100
|
30
|
35
|
42
|
60
|
95
|
|
|
144
|
36
|
42
|
51
|
72
|
114
|
|
|
196
|
42
|
48
|
59
|
84
|
133
|
|
|
256
|
48
|
55
|
68
|
96
|
152
|
|
|
324
|
54
|
62
|
76
|
108
|
171
|
|
|
400
|
60
|
69
|
85
|
120
|
190
|
|
|
旋转电磁铁起动扭矩
(N·m 20℃) 回位发条起始扭矩 0.009-0.012N·m |
20°
|
0.04
|
0.052
|
0.081
|
0.15
|
0.1
|
|
35°
|
0.29
|
0.04
|
0.063
|
0.115
|
0.23
|
|
|
45°
|
0.017
|
0.022
|
0.04
|
0.092
|
0.16
|
|
|
70°
|
0.012
|
0.017
|
0.022
|
0.046
|
0.075
|
|
