点击图片查看原图
KB2UD06-M5,KB2UD06-M6,KB2UD06-1S,KB2UD06-2S,外螺五通接头,价格
| 适用气管外径 ￠D | 型号 | 连接螺纹 | 接头外六角 | 接头外形 | 安装孔距 | ||||||
| 规格 | A/A1 | H | S | ￠ | ￠1 | L | C | B | B1 | ||
| ￠4 | KB2UD04-M5 | M5×0.8 | 4 | 3.3 | 14 | 11 | 132. | 31.5 | 10.6 | 17.8 | 8.8 |
| KB2UD04-M6 | M6×1.0 | 4.8 | |||||||||
| KB2UD04-1S | 1/8’ | 7.5 | 4 | ||||||||
| KB2UD04-2S | 1/4’ | 10.5 | 5.5 | ||||||||
| ￠6 | KB2UD06-M5 | M5×0.8 | 4 | 3.3 | 17 | 13.2 | 15.6 | 37.2 | 12.8 | 20.8 | 11.3 |
| KB2UD06-M6 | M6×1.0 | 4.8 | |||||||||
| KB2UD06-1S | 1/8’ | 7.5 | 4 | ||||||||
| KB2UD06-2S | 1/4’ | 10.5 | 5.5 | ||||||||
