J145X-2.5-DN80,J145X-2.5-DN100,J145X-2.5-DN125,J145X-2.5-DN150,J145X-2.5-DN200,J145X-2.5-DN250,J145X-2.5-DN300,J145X-2.5-DN350,J145X-2.5-DN400, J145X-2.5-DN450,J145X-2.5-DN500,J145X-2.5-DN600,隔膜式电动遥控阀

点击图片查看原图

型号：	J145X-1.0-DN50,J145X-1.0-DN65,J145X-1.0-DN80,J145X-1.0-DN100,J145X-1.0-DN125,J145X-1.0-DN150,J145X-1
PDF下载：	如需产品详细说明请与销售客服联系
浏览次数：	663

公司基本资料信息

联系人销售员 1731(先生)
电话13861877712
地区江苏-无锡市
地址无锡市会北路28-135

详细说明

J145X-1.0-DN50,J145X-1.0-DN65,J145X-1.0-DN80,J145X-1.0-DN100,J145X-1.0-DN125,J145X-1.0-DN150,J145X-1.0-DN200,J145X-1.0-DN250,J145X-1.0-DN300,J145X-1.0-DN350,J145X-1.0-DN400,J145X-1.0-DN450,

J145X-1.0-DN500,J145X-1.0-DN600,J145X-1.6-DN50,J145X-1.6-DN65,J145X-1.6-DN80,J145X-1.6-DN100,J145X-1.6-DN125,J145X-1.6-DN150,J145X-1.6-DN200,

J145X-1.6-DN250,J145X-1.6-DN300,J145X-1.6-DN350,J145X-1.6-DN400,J145X-1.6-DN450,J145X-1.6-DN500,J145X-1.6-DN600,J145X-2.5-DN50,J145X-2.5-DN65,

J145X-2.5-DN80,J145X-2.5-DN100,J145X-2.5-DN125,J145X-2.5-DN150,J145X-2.5-DN200,J145X-2.5-DN250,J145X-2.5-DN300,J145X-2.5-DN350,J145X-2.5-DN400,

J145X-2.5-DN450,J145X-2.5-DN500,J145X-2.5-DN600,隔膜式电动遥控阀

一、概述：

J145X隔膜式电动遥控阀是一种用于消防用水与生活用水并联的供水系统中，用来调配供水方向的阀门。当火灾发生时，消防急需大量用水，立即切断生活用水，确保足够的消防用水；当消防停止用水压力减小时，阀门自动打开，呈常开状态，恢复生活供水。该阀使系统无须另设专门的消防单独供水管网，大大地节约了建设成本和用水量。阀门控制灵敏度高，安全可靠，调试简便，使用寿命长

二、主要技术参数

1、公称压力：1.0MPa、1.6MPa、2.5MPa

2、适用介质：水

3、介质温度：0～80℃

4、电磁阀的说明：电压：交流220V直流：24V

三、主要外形连接尺寸

DN	50	65	80	100	125	150	200	250	300	350	400	450	500	600
L	205	216	250	320	365	415	500	605	698	787	914	978	978	1150
H	320	367	400	452	522	592	696	810	943	1200	1230	1230	1270	1600

J145X-1.0-DN50,J145X-1.0-DN65,J145X-1.0-DN80,J145X-1.0-DN100,J145X-1.0-DN125,J145X-1.0-DN150,J145X-1.0-DN200,J145X-1.0-DN250,J145X-1.0-DN300,J145X-1.0-DN350,J145X-1.0-DN400,J145X-1.0-DN450, J145X-1.0-DN500,J145X-1.0-DN600,J145X-1.6-DN50,J145X-1.6-DN65,J145X-1.6-DN80,J145X-1.6-DN100,J145X-1.6-DN125,J145X-1.6-DN150,J145X-1.6-DN200, J145X-1.6-DN250,J145X-1.6-DN300,J145X-1.6-DN350,J145X-1.6-DN400,J145X-1.6-DN450,J145X-1.6-DN500,J145X-1.6-DN600,J145X-2.5-DN50,J145X-2.5-DN65, J145X-2.5-DN80,J145X-2.5-DN100,J145X-2.5-DN125,J145X-2.5-DN150,J145X-2.5-DN200,J145X-2.5-DN250,J145X-2.5-DN300,J145X-2.5-DN350,J145X-2.5-DN400, J145X-2.5-DN450,J145X-2.5-DN500,J145X-2.5-DN600,隔膜式电动遥控阀
